Water selective MFI zeolite membranes for application in the Fischer Tropsch Synthesis

Simple item page
dc.contributor.advisorMöller, Klausen_ZA
dc.contributor.authorSadat Rezai, Seyed Alirezaen_ZA
dc.date.accessioned2014-08-28T09:17:13Z
dc.date.available2014-08-28T09:17:13Z
dc.date.issued2005en_ZA
dc.description.abstractSelective removal of water from the Fischer-Tropsch Synthesis (FTS) during reaction may allow the use of a cobalt catalyst with crystal size <6 nm hence increasing the catalyst activity. Zeolite membranes are a potential route to in-situ water removal due to their chemical and thermal stability under FTS reaction conditions. Zeolite membranes with a low Si/ Al ratio are hydrophilic. It has been hypothesised that reducing the Si/ Al ratio will result in increased water selectivity and permeance. It is also hypothesised that the separation process can be modelled using the MaxwellStefan (MS) formulation. MFI zeolite membranes were synthesised on a-alumina supports, of varying Si/ Al ratio. Two synthesis techniques were used: viz. with and without the assistance of structure directing agents. The membrane physical properties were characterised by SEM and XRD. Membrane quality was evaluated using n-hexane porosimetry. Single gas and mixture separations were carried out. A trans-membrane pressure gradient was applied in single gas measurements. Binary and ternary mixture separations were carried out using a model reaction mixture that approximates FTS conditions. This mixture was fed to a Wicke-Kallenbach cell. The total pressure on both sides of the membrane was equal, with a sweep gas applied to remove the permeate. Single gas permeation measurements on a blank support shows that viscous and knudsen flow are the dominant transport mechanisms in the support. A single gas permeation model for the zeolite membranes show that viscous and knudsen flow still dominate in pure component measurements. This due to the high flux through the zeolite films. During mixture separations viscous and knudsen flow are negligible as there is no pressure gradient. Comparing pure component and binary mixture separations the flux of hydrogen decreases by more than two orders of magnitude for the binary case. In the binary system water adsorption results in blockage of pores hence hydrogen permeance is reduced. Binary H20/H2 separation selectivity increases with decreasing Si/ Al ratio. Increasing temperature results in a decrease in this selectivity. Water adsorption decreases with increasing temperature hence hydrogen can permeate faster. With the addition of n-hexane as a third component, permeance of water and hydrogen decrease, however ternary H20/H2 separation selectivity increases. The Maxwell-Stefan model developed does not predict binary hydrogen permeation well. Permeance is much higher than predicted by the model possibly due to defects. Ternary hydrogen permeance is however more accurately predicted. Water and n-hexane permeances are predicted well by the model.en_ZA
dc.identifier.apacitationSadat Rezai, S. A. (2005). <i>Water selective MFI zeolite membranes for application in the Fischer Tropsch Synthesis</i>. (Thesis). University of Cape Town ,Faculty of Engineering & the Built Environment ,Department of Chemical Engineering. Retrieved from http://hdl.handle.net/11427/6699en_ZA
dc.identifier.chicagocitationSadat Rezai, Seyed Alireza. <i>"Water selective MFI zeolite membranes for application in the Fischer Tropsch Synthesis."</i> Thesis., University of Cape Town ,Faculty of Engineering & the Built Environment ,Department of Chemical Engineering, 2005. http://hdl.handle.net/11427/6699en_ZA
dc.identifier.citationSadat Rezai, S. 2005. Water selective MFI zeolite membranes for application in the Fischer Tropsch Synthesis. University of Cape Town.en_ZA
dc.identifier.ris TY - Thesis / Dissertation AU - Sadat Rezai, Seyed Alireza AB - Selective removal of water from the Fischer-Tropsch Synthesis (FTS) during reaction may allow the use of a cobalt catalyst with crystal size <6 nm hence increasing the catalyst activity. Zeolite membranes are a potential route to in-situ water removal due to their chemical and thermal stability under FTS reaction conditions. Zeolite membranes with a low Si/ Al ratio are hydrophilic. It has been hypothesised that reducing the Si/ Al ratio will result in increased water selectivity and permeance. It is also hypothesised that the separation process can be modelled using the MaxwellStefan (MS) formulation. MFI zeolite membranes were synthesised on a-alumina supports, of varying Si/ Al ratio. Two synthesis techniques were used: viz. with and without the assistance of structure directing agents. The membrane physical properties were characterised by SEM and XRD. Membrane quality was evaluated using n-hexane porosimetry. Single gas and mixture separations were carried out. A trans-membrane pressure gradient was applied in single gas measurements. Binary and ternary mixture separations were carried out using a model reaction mixture that approximates FTS conditions. This mixture was fed to a Wicke-Kallenbach cell. The total pressure on both sides of the membrane was equal, with a sweep gas applied to remove the permeate. Single gas permeation measurements on a blank support shows that viscous and knudsen flow are the dominant transport mechanisms in the support. A single gas permeation model for the zeolite membranes show that viscous and knudsen flow still dominate in pure component measurements. This due to the high flux through the zeolite films. During mixture separations viscous and knudsen flow are negligible as there is no pressure gradient. Comparing pure component and binary mixture separations the flux of hydrogen decreases by more than two orders of magnitude for the binary case. In the binary system water adsorption results in blockage of pores hence hydrogen permeance is reduced. Binary H20/H2 separation selectivity increases with decreasing Si/ Al ratio. Increasing temperature results in a decrease in this selectivity. Water adsorption decreases with increasing temperature hence hydrogen can permeate faster. With the addition of n-hexane as a third component, permeance of water and hydrogen decrease, however ternary H20/H2 separation selectivity increases. The Maxwell-Stefan model developed does not predict binary hydrogen permeation well. Permeance is much higher than predicted by the model possibly due to defects. Ternary hydrogen permeance is however more accurately predicted. Water and n-hexane permeances are predicted well by the model. DA - 2005 DB - OpenUCT DP - University of Cape Town LK - https://open.uct.ac.za PB - University of Cape Town PY - 2005 T1 - Water selective MFI zeolite membranes for application in the Fischer Tropsch Synthesis TI - Water selective MFI zeolite membranes for application in the Fischer Tropsch Synthesis UR - http://hdl.handle.net/11427/6699 ER - en_ZA
dc.identifier.urihttp://hdl.handle.net/11427/6699
dc.identifier.vancouvercitationSadat Rezai SA. Water selective MFI zeolite membranes for application in the Fischer Tropsch Synthesis. [Thesis]. University of Cape Town ,Faculty of Engineering & the Built Environment ,Department of Chemical Engineering, 2005 [cited yyyy month dd]. Available from: http://hdl.handle.net/11427/6699en_ZA
dc.language.isoeng
dc.publisher.departmentDepartment of Chemical Engineeringen_ZA
dc.publisher.facultyFaculty of Engineering and the Built Environment
dc.publisher.institutionUniversity of Cape Town
dc.subject.otherEngineeringen_ZA
dc.titleWater selective MFI zeolite membranes for application in the Fischer Tropsch Synthesisen_ZA
dc.typeMaster Thesis
dc.type.qualificationlevelMasters
dc.type.qualificationnameMSc
uct.type.filetypeText
uct.type.filetypeImage
uct.type.publicationResearchen_ZA
uct.type.resourceThesisen_ZA
